STAINLESS STEEL TUBULAR HEAT EXCHANGER 105.6 M² CALDERERIA DEL CARBONO E-113
Reference
:
C14125
Tubular heat exchanger manufactured by CALDERERIA DEL CARBONO, model E-113.
Heat transfer surface: 105.6 m²
Year: 2005
Structure: mounted on 4 brackets
Connections:
Lateral: DN40, DN100, Ø615 mm
Top: DN25
Bottom: DN150
Material
Stainless steel
Technical features
Model
E-113
Year of manufacture
2005
Shell-Side Volume
1450 L
Tubes volume
560 L
Tube side passes
4
Number of Tubes
100
Tube working temperature
25 ºC
Working pressure of the tubes
6 bar
Working temperature of the shell
120 ºC
Working pressure of the shell
0,9 bar
Dimensions
Length of the tubes
4000 mm
Inner Tube Diameter
21 mm
Transport information
Length
5300 mm
Width
1400 mm
Documentation
No documentation
Heat Exchange Surface
Heat Exchange Surface
105.60 m2
Condition
As is
Made by
Caldereria del Carbono
Request your quote here
Download technical data sheet
